Oakton CON 610
多参数型号供您的电导率/溶解氧测量需求
可编程的“校准到期日期”增加数据完整性
最多可存储500个数据点,时间和日期戳按照GLP规范
通过红外无线下载数据
这些顶级的防水仪表提供单一或者多参数测量能力,以满足所有的测试需求。IP67级外壳允许在肮脏和潮湿的环境中使用而不损害仪表。存储带有手动或自动数据记录500个数据点,并下载到电脑或印表机的红外线(IrDA)的无线技术,无需额外的电源线。用户可选择“校准”,和设置点报警,自动或手动标准识别,以及单点或多点校准提供了灵活性以满足您的数据质量目标。大的背光图形液晶显示测量值和单位,温度,时间,电池寿命,和菜单选项。
包含:仅仪表包括:多功能支架,软件,和四节AA电池。
仪表探头增加: 2 -电池电导率探头(35408-52)和溶解氧探头(35640-50)。
仪表套件进一步增加:塑料手提箱,橡胶保护套,和校准液。
Multiple parameter models for all of your conductivity/DO measurement needs
Programmable ”calibration due” date for increased data integrity
Stores up to 500 data points with time-and-date stamp for GLP compliance
Wirelessly download data via IrDA port
These top-of-the-line waterproof meters offer single or multiparameter measurement capabilities to meet all of your testing needs. The IP67-rated housing allows use in dirty and wet environments without harm to the meter. Store up to 500 data points and download to computer or printer with the infrared (IrDA) wireless technology—no need for additional cords. User-selectable “calibration due” and set point alarms, automatic or manual standards recognition, and single- or multiple-point calibration provide flexibility in meeting you data quality objectives. The large backlit, graphic LCD shows the measured value and units, temperature, time, battery life, and menu options.
What’s Included:
Meter only includes: multiprobe holder, software, and four AA batteries.
Meter with probes adds: 2-cell conductivity probe (35408-52) and dissolved oxygen probe (35640-50).
Meter kits further add: plastic carrying case, protective rubber boot, and calibration solutions.
产品规格
|
产品类型
|
多参数计
|
仪表风格
|
手提
|
外形尺寸(W)
|
3-1/4
|
尺寸(“H)
|
7-1/4
|
尺寸(“D)
|
2-1/4
|
范围(电导率)
|
0至500毫秒
|
范围(TDS)
|
0至500个百分点
|
范围(盐度)
|
0至80个百分点
|
范围(电阻)
|
0到20兆欧姆
|
范围(溶解氧)
|
0至600%,0到49.49 mg / L
|
范围(温度°C)
|
-10至110
|
范围(温华氏度)
|
14至230
|
分辨率(温度)
|
0.1°C /°F
|
分辨率(电导率)
|
0.01,0.1μS0.001,0.01,0.1毫秒
|
分辨率(TDS)
|
0.01,百万分之0.1,0.001,0.01,0.1个百分点
|
分辨率(电阻)
|
0.01,0.001 M欧姆; 0.1 k欧姆,0.1,0.01,0.001欧姆
|
分辨率(溶解氧)
|
0.1%,0.01毫克/升
|
分辨率(盐度)
|
0.01,0.1百万分之0.001,0.01个百分点
|
准确度(温度)
|
±0.9°F(±0.5°C)
|
精度(电阻)
|
±1%满量程
|
精度(溶解氧)
|
±2%;±0.2毫克/升
|
精度(电导率)
|
±1%满量程
|
精度(TDS)
|
±1%满量程
|
准确度(盐度)
|
±1%满量程
|
温度补偿
|
自动或手动
|
显示
|
液晶显示
|
接口
|
RS-232
|
防水
|
是
|
功率
|
四节AA电池(附带)或可选的通用AC适配器
|
数据记录(点)
|
500
|
品牌
|
OAKTON
|
型号
|
CON 610
|
Specifications
|
Product Type
|
Multiparameter Meters
|
Meter style
|
Portable
|
Dimensions (” W)
|
3-1/4
|
Dimensions (” H)
|
7-1/4
|
Dimensions (” D)
|
2-1/4
|
Range (Conductivity)
|
0 to 500 mS
|
Range (TDS)
|
0 to 500 ppt
|
Range (Salinity)
|
0 to 80 ppt
|
Range (Resistivity)
|
0 to 20 M ohm
|
Range (Dissolved oxygen)
|
0 to 600%; 0 to 49.49 mg/L
|
Range (Temperature °C)
|
-10 to 110
|
Range (Temperature °F)
|
14 to 230
|
Resolution (Temperature)
|
0.1°C/°F
|
Resolution (Conductivity)
|
0.01, 0.1 µS; 0.001, 0.01, 0.1 mS
|
Resolution (TDS)
|
0.01, 0.1 ppm, 0.001, 0.01, 0.1 ppt
|
Resolution (Resistivity)
|
0.01, 0.001 m ohm; 0.1 k ohm; 0.1, 0.01, 0.001 ohm
|
Resolution (Dissolved oxygen)
|
0.1%, 0.01 mg/L
|
Resolution (Salinity)
|
0.01, 0.1 ppm; 0.001, 0.01 ppt
|
Accuracy (Temperature)
|
±0.9°F (±0.5°C)
|
Accuracy (Resistivity)
|
±1% full-scale
|
Accuracy (Dissolved oxygen)
|
±2%; ±0.2 mg/L
|
Accuracy (Conductivity)
|
±1% full-scale
|
Accuracy (TDS)
|
±1% full-scale
|
Accuracy (Salinity)
|
±1% full-scale
|
Temperature compensation
|
Automatic or manual
|
Display
|
LCD
|
Interface
|
RS-232
|
Waterproof
|
Yes
|
Power
|
Four AA batteries (included) or optional universal AC adapter
|
Datalogging (points)
|
500
|
Brand
|
Oakton
|
Model
|
CON 610
|
