Oakton PH700仪表及集成PH探头
Oakton pH 700 Benchtop Meter with “all-in-one” pH electrode
专为当今拥挤的实验室台面设计的!
占地面积比其他台式仪表小约40%
大显示屏便于读数观看
数据记录,让您存储和调用多达100个数据集
易于使用的,基于微处理器的pH为700台式仪表测量pH值,毫伏,相对mV和温度。大,双显示LCD提供了极好的能见度。即使温度波动,也可自动温度补偿(ATC)维持读数精度,五点pH校准,自动识别缓冲液为美国(pH值1.68,4.01,7.00,10.01,12.45)和NIST pH缓冲液(pH值1.68,4.01,6.86,9.18,12.45),更容易校准,您所需的任何要求均可满足。
仪表具有HOLD功能,ATC,可选择°F或°C的测量,回收电极污水偏移,和电极诊断。方便快速参考卡让程序在任何时候都得心应手。仪表可接受任何pH或ORP电极带BNC连接器.单独订购PH电极。
内容包括:
通用110/240伏交流电源和适配器。
Designed for today’s crowded laboratory benchtops!
Compact footprint is over 40% smaller than other benchtop meters
Large display permits easier readout viewing
Datalogging allows you to store and recall up to 100 data sets
The easy-to-use, microprocessor-based pH 700 benchtop meter measures pH, mV, relative mV, and temperature. The large, dual-display LCD provides excellent visibility—even from a distance. Automatic temperature compensation (ATC) maintains reading accuracy even with fluctuating temperatures. Five-point pH calibration, with automatic buffer recognition for both USA (pH 1.68, 4.01, 7.00, 10.01, 12.45) and NIST (pH 1.68, 4.01, 6.86, 9.18, 12.45) pH buffers, makes for easy calibration no matter which requirement you need to meet.
Meter features HOLD, ATC, selectable °f or °C measurement, recall of electrode slopand offset, and electrode diagnostics. The convenient pull-out quick reference card keeps procedures handy at all times. Meter accepts any pH or ORP electrodes with a BNC connector.Meter only, order pH electrode separately.
What’s Included:
universal 110/240 VAC power supply and adapters.
产品规格
|
产品类型
|
pH计
|
仪表风格
|
台式
|
外形尺寸(W)
|
6-7/8
|
尺寸(“H)
|
2-3/4
|
外形尺寸(L)
|
6-1/8
|
范围(pH值)
|
-2.00至16.00
|
范围(mV)
|
±2000
|
范围(温度°C)
|
0.0至100.0
|
范围(温华氏度)
|
32至212
|
分辨率(pH值)
|
0.01
|
分辨率(温度)
|
0.1°C /°F
|
分辨率(MV)
|
0.1内超过±199.9±199.9,1
|
准确度(PH)
|
±0.01
|
准确度(温度)
|
±0.9°F(±0.5°C)
|
精度(mV)
|
±0.2±2±199.9 mV的范围内,超出了199.9毫伏
|
温度补偿
|
自动或手动
|
显示
|
液晶显示
|
校准
|
5
|
缓冲液识别
|
美国,NIST
|
功率
|
100/240 VAC,50/60赫兹
|
数据记录(点)
|
100
|
符合CE认证
|
是
|
品牌
|
OAKTON
|
型号
|
pH值700
|
Specifications
|
Product Type
|
pH Meters
|
Meter style
|
Benchtop
|
Dimensions (” W)
|
6-7/8
|
Dimensions (” H)
|
2-3/4
|
Dimensions (” L)
|
6-1/8
|
Range (pH)
|
-2.00 to 16.00
|
Range (mV)
|
±2000
|
Range (Temperature °C)
|
0.0 to 100.0
|
Range (Temperature °F)
|
32 to 212
|
Resolution (pH)
|
0.01
|
Resolution (Temperature)
|
0.1°C/°F
|
Resolution (mV)
|
0.1 within ±199.9 , 1 beyond ±199.9
|
Accuracy (pH)
|
±0.01
|
Accuracy (Temperature)
|
±0.9°F (±0.5°C)
|
Accuracy (mV)
|
±0.2 within ±199.9 mV, ±2 beyond 199.9 mV
|
Temperature compensation
|
Automatic or manual
|
Display
|
LCD
|
Calibration
|
5
|
Buffer recognition
|
USA, NIST
|
Power
|
100/240 VAC, 50/60 Hz
|
Datalogging (points)
|
100
|
CE Compliance
|
Yes
|
Brand
|
Oakton
|
Model
|
pH 700
|
