WTW 3410多参数测量仪/SenTix 940-3及 TetraCon 925-3探头
WTW Multi 3410 Multiparameter Meter w/SenTix 940-3 and TetraCon 925-3 probes
单通道多参数仪表准确地选择你需要的功能！
图形显示连续测量控制测量值和校准范围
高精度传感器以图形方式显示，便于电极诊断
防水USB连接超灵活数据输出
WTW单通道复线仪表是pH值，电导率和溶解氧测量仪器坚固耐用。Multi 3410显示任何类型的传感器测量通道。订购单机仪表或便携套件，经济仪表/传感器包。
多行仪表具有高分辨率彩色显示器。测量的读数，通道和连接器的位置信息读取一目了然。当是时候进行校准或更换，高精度传感器的诊断信息也就显示在独特的显示上，普通显示器校准测量范围，确保了精确的读数。
智能数字传感器（IDS）已被证明优于其他类型的传感器。数字传感器都有单独的IDed，并自动登录到仪表，一旦连接。与初始校准传感器比较每个校准后存储在传感器对传感器健康提供有价值的信息。数字处理和数据传输的传感器测量非常精确。通过防水快锁传感器连接到附加传感器。
多行仪表也超过国家最先进的数据管理。仪表存储多达10,000符合GLP要求的测量。通过防水USB或微型USB接口传输数据。防水连接适合便携式现场测量。
包括：四节AA电池，CD-ROM，电缆和电源
仪表套件增添：指示pH值，电导率，溶解氧传感器，手提箱，校准套件，支架和样品杯。
Single-channel multiparameter meters—select exactly the features you need!
Graphical display of measured value and calibrated range for continuous measurement control
Sensor quality is displayed graphically for easy electrode diagnostics
Waterproof USB connection for ultra-flexible data output
WTW single-channel MultiLine meters are rugged instruments for pH, conductivity, and dissolved oxygen measurement. Multi 3410 displays one measurement channel of any sensor type. Order stand-alone meters or convenient kits for economical meter/sensor bundles.
MultiLine meters feature brilliant high resolution color displays. Measured readings, channel, and connector position information can be read at a glance. Unique display configuration also provides diagnostic information on sensor quality—easily tell when it is time for calibration or replacement! Plain display of calibrated measurement range ensures accurate readings.
Intelligent digital sensors (IDS) have proven advantages over other sensor types. Digital sensors are individually IDed and automatically log on to meters once connected. Sensors compare each following calibration with the initial calibration stored in the sensor providing valuable information on sensor health. Digital processing and data transfer of sensor measurement gives extremely precise measurements. Attach sensors via waterproof quick-lock sensor connections.
MultiLine meters also over state-of-the-art data management. Meters store up to 10,000 GLP-compliant measurements. Export data via waterproof USB or mini-USB interface. Waterproof connections are ideal for portable field measurements.
What’s included: four AA batteries, CD-ROM, cable and power supply
Meter kits add: indicated pH, conductivity, or DO sensors, carrying case, calibration kit, stand and sample beaker.
|
产品规格
|
|
产品类型
|
多参数计
|
|
仪表风格
|
手提
|
|
外形尺寸（W）
|
7
|
|
尺寸（“H）
|
3-1/8
|
|
尺寸（“D）
|
2-1/4
|
|
范围（pH值）
|
-2.000 20.000
|
|
范围（mV的）
|
±1250±2000
|
|
范围（电导率）
|
0到2000毫秒; 0.00至19.99μS
|
|
范围（TDS）
|
0到1999毫克/升，0到199.9克/升
|
|
范围（盐度）
|
0至70个百分点
|
|
范围（电阻）
|
0到20兆欧姆
|
|
范围（溶解氧）
|
0至20毫克/升
|
|
范围（温度°C）
|
-5〜105
|
|
范围（温华氏度）
|
23至221
|
|
分辨率（pH值）
|
0.1，0.01，0.001
|
|
分辨率（温度）
|
0.1°C
|
|
分辨率（MV）
|
0.1，1
|
|
分辨率（电导率）
|
1毫秒; 0.01μS
|
|
分辨率（TDS）
|
1毫克/升，0.1 g / L的
|
|
分辨率（电阻）
|
0.01 M欧姆
|
|
分辨率（溶解氧）
|
0.01毫克/升，0.1％的饱和度
|
|
分辨率（盐度）
|
0.1
|
|
准确度（PH）
|
±0.004
|
|
准确度（温度）
|
±0.2°
|
|
精度（mV）
|
±0.2
|
|
精度（电阻）
|
读数的±0.5％
|
|
精度（溶解氧）
|
读数的±0.5％
|
|
精度（电导率）
|
读数的±0.5％
|
|
精度（TDS）
|
读数的±0.5％
|
|
准确度（盐度）
|
读数的±0.5％
|
|
温度补偿
|
自动或手动
|
|
显示
|
液晶显示
|
|
校准
|
5
|
|
防水
|
是的
|
|
缓冲液识别
|
NIST，DIN
|
|
功率
|
四节AA电池（附带）
|
|
数据记录（点）
|
10,000
|
|
符合CE认证
|
是的
|
|
品牌
|
WTW
|
|
Specifications
|
|
Product Type
|
Multiparameter Meters
|
|
Meter style
|
Portable
|
|
Dimensions (” W)
|
7
|
|
Dimensions (” H)
|
3-1/8
|
|
Dimensions (” D)
|
2-1/4
|
|
Range (pH)
|
-2.000 to 20.000
|
|
Range (mV)
|
±1250, ±2000
|
|
Range (Conductivity)
|
0 to 2000 mS; 0.00 to 19.99 µS
|
|
Range (TDS)
|
0 to 1999 mg/L; 0 to 199.9 g/L
|
|
Range (Salinity)
|
0 to 70 ppt
|
|
Range (Resistivity)
|
0 to 20 M ohm
|
|
Range (Dissolved oxygen)
|
0 to 20 mg/L
|
|
Range (Temperature °C)
|
-5 to 105
|
|
Range (Temperature °F)
|
23 to 221
|
|
Resolution (pH)
|
0.1, 0.01, 0.001
|
|
Resolution (Temperature)
|
0.1°C
|
|
Resolution (mV)
|
0.1, 1
|
|
Resolution (Conductivity)
|
1 mS; 0.01 µS
|
|
Resolution (TDS)
|
1 mg/L; 0.1 g/L
|
|
Resolution (Resistivity)
|
0.01 M ohm
|
|
Resolution (Dissolved oxygen)
|
0.01 mg/L; 0.1% saturation
|
|
Resolution (Salinity)
|
0.1
|
|
Accuracy (pH)
|
±0.004
|
|
Accuracy (Temperature)
|
±0.2°
|
|
Accuracy (mV)
|
±0.2
|
|
Accuracy (Resistivity)
|
±0.5% of reading
|
|
Accuracy (Dissolved oxygen)
|
±0.5% of reading
|
|
Accuracy (Conductivity)
|
±0.5% of reading
|
|
Accuracy (TDS)
|
±0.5% of reading
|
|
Accuracy (Salinity)
|
±0.5% of reading
|
|
Temperature compensation
|
Automatic or manual
|
|
Display
|
LCD
|
|
Calibration
|
5
|
|
Waterproof
|
Yes
|
|
Buffer recognition
|
NIST, DIN
|
|
Power
|
Four AA batteries (included)
|
|
Datalogging (points)
|
10,000
|
|
CE Compliance
|
Yes
|
|
Brand
|
WTW
|
