Oakton PC700仪表/ pH电极,电导率/温度探头,电极支架和NIST校准
Oakton PC700 Meter w/pH electrode, conductivity/temp probe, electrode stand and NIST-traceable Calibration
一键测量,轻松切换PH,mV,电导率,TDS,和温度
节省空间设计相较于工作台上的其他仪表占用空间更小
大显示屏可以让你从实验室外测量
每次测量时电导率和TDS自动量程助您选择最佳分辨率
PC700仪表提供了一种新的紧凑型设计,40%以上小于其他台式仪表。大显示屏在远处也易于阅读。双显示器同时读取测量参数和温度,使其一目了然。该仪器具有美国和NIST缓冲套pH值自动缓冲识别(1.68,4.01,7.00,10.01和12.45,1.68,4.01,6.18,9.86,12.45),自动或手动温度补偿,温度可选°F或°C,显示保持,防水的键盘。
前校准点,电极的斜率和偏移,电导率/ TDS电池常数存储在内存中快速方便地检索。您还可以存储100个数据集在仪表的内存,以供日后检索。方便快速拔出参考卡,指尖按键。
包含:通用100/240伏电源,电源适配器,电极支架
仪表探头增加:复合pH电极(35805-04)和电导率/温度探头(35608-74)。
Easily toggle between pH, mV, conductivity, TDS, and temperature measurements at the touch of a button
Space-saving design takes up less room on the bench than other meters
Large display lets you see your measurements from across the lab
Conductivity and TDS autoranging chooses the best resolution for each measurement
The PC700 meter offers a new compact design that is over 40% smaller than other benchtop meters. The large display is easy to read even at a distance. Dual-display allows you to read both a measured parameter and temperature at a glance. The meter features pH auto-buffer recognition for both USA and NIST buffer sets (1.68, 4.01, 7.00, 10.01 and 12.45 or 1.68, 4.01. 6.18. 9.86, and 12.45), automatic or manual temperature compensation, temperature selectable in either °F or °C, display Hold, and water-resistant membrane keypad.
Previous calibration points, electrode slope and offset, and conductivity/TDS cell constants are stored in memory for quick and easy retrieval. You can also store up to 100 data sets in the meter’s memory for retrieval later. The convenient pull-out quick reference card keeps keypad functions at your fingertips.
What’s Included:
universal 100/240 VAC power supply, power adapters, and electrode stand.
Meter with probes adds: combination pH electrode (35805-04) and conductivity/temperature probe (35608-74).
|
产品规格
|
|
产品类型
|
多参数计
|
|
仪表风格
|
台式
|
|
尺寸(“H)
|
6-7/8
|
|
尺寸(“D)
|
2-3/4
|
|
外形尺寸(L)
|
6-1/8
|
|
范围(pH值)
|
-2.00至16.00
|
|
范围(mV)
|
±2000
|
|
范围(电导率)
|
0.0μS到200毫秒
|
|
范围(TDS)
|
0.00 ppm to 100.0 ppt @ 0.5 factor (200.0 ppt @ 1.0 factor)
|
|
范围(温度°C)
|
0到100
|
|
范围(温华氏度)
|
32至212
|
|
分辨率(pH值)
|
0.01
|
|
分辨率(温度)
|
0.1°C /°F
|
|
分辨率(MV)
|
0.1内超过±199.9±199.9,1
|
|
分辨率(电导率)
|
0.01,0.1,1μS0.01,0.1毫秒
|
|
分辨率(TDS)
|
0.01,0.1,1 ppm的0.01,0.1个百分点;
|
|
准确度(PH)
|
±0.01
|
|
准确度(温度)
|
±0.9°F(±0.5°C)
|
|
精度(mV的)
|
±0.2±2±199.9 mV的范围内,超出了199.9毫伏
|
|
精度(电导率)
|
±1%满量程
|
|
精度(TDS)
|
±1%满量程
|
|
温度补偿
|
自动或手动
|
|
显示
|
液晶显示
|
|
校准
|
5
|
|
缓冲液识别
|
美国NIST,DIN
|
|
功率
|
110/240 VAC
|
|
数据记录(点)
|
100
|
|
符合CE认证
|
是
|
|
品牌
|
OAKTON
|
|
Specifications
|
|
Product Type
|
Multiparameter Meters
|
|
Meter style
|
Benchtop
|
|
Dimensions (” H)
|
6-7/8
|
|
Dimensions (” D)
|
2-3/4
|
|
Dimensions (” L)
|
6-1/8
|
|
Range (pH)
|
-2.00 to 16.00
|
|
Range (mV)
|
±2000
|
|
Range (Conductivity)
|
0.0 µS to 200 mS
|
|
Range (TDS)
|
0.00 ppm to 100.0 ppt @ 0.5 factor (200.0 ppt @ 1.0 factor)
|
|
Range (Temperature °C)
|
0 to 100
|
|
Range (Temperature °F)
|
32 to 212
|
|
Resolution (pH)
|
0.01
|
|
Resolution (Temperature)
|
0.1°C/°F
|
|
Resolution (mV)
|
0.1 within ±199.9, 1 beyond ±199.9
|
|
Resolution (Conductivity)
|
0.01, 0.1, 1 µS; 0.01, 0.1 mS
|
|
Resolution (TDS)
|
0.01, 0.1, 1 ppm; 0.01, 0.1 ppt
|
|
Accuracy (pH)
|
±0.01
|
|
Accuracy (Temperature)
|
±0.9°F (±0.5°C)
|
|
Accuracy (mV)
|
±0.2 within ±199.9 mV, ±2 beyond 199.9 mV
|
|
Accuracy (Conductivity)
|
±1% full scale
|
|
Accuracy (TDS)
|
±1% full scale
|
|
Temperature compensation
|
Automatic or manual
|
|
Display
|
LCD
|
|
Calibration
|
5
|
|
Buffer recognition
|
USA, NIST, DIN
|
|
Power
|
110/240 VAC
|
|
Datalogging (points)
|
100
|
|
CE Compliance
|
Yes
|
|
Brand
|
Oakton
|
