适用于19种 可相互更换、有射频标记的移液头,Versette™提供杰出的多功能移液性能,可满足需要从单通道至384通道进行自动移液的各种应用的需求。Versette移液工作平台可配置使用一次性吸头和固定式吸头的移液头,移液体积范围从0.1 µl至1250 µl。为进一步优化性能,单通道、8通道及12通道移液头使用可实现安全密封的Thermo Scientific ClipTips吸头。这种吸头独特的卡入式设计,在插入及弹出时只需要最小的机械力,从而降低仪器和分液头的损耗,延长使用寿命。96及384通道的移液头使用Thermo Scientific D.A.R.T.s吸头,采用表面密封技术来保证所有通道的精准移液。


Versette 提供两种操作台配置以提高可扩展性。可方便更换的两板位及六板位操作台为仪器的独立使用和自动化整合提供了极大的灵活性。由于具有紧凑的外观尺寸,加之空间节约型双层式设计的六板位操作台,Versette可以安置于任何工作台面及封闭工作空间。并且, 所有操作台均可装配安全挡板,可为实验材料提供封闭式空间、减少污染,而无需额外的空间分隔设施。

无论是简单还是复杂的移液程序,既可通过直观的随机LCD触摸屏使用内置软件,又可通过计算机使用专门的Thermo Scientific ControlMate软件进行编程。Thermo Scientific Versette自动液体处理平台具备先进的仪器操控性、实验精确性和全功能性,是从手持移液向自动移液过渡,或建立整合的自动移液系统的理想选择。

Versatile enough to fit any lab from low to high throughput. Scalable to fit a lab’s needs today and tomorrow. Easy to integrate into any size lab.
  • Compatible with nineteen interchangeable pipetting heads ranging from single to 384-channels
  • Pipetting heads are available in disposable and fixed tip formats
  • Total volume range of 0.1µL to 1250
  • All pipetting heads include RFID tags to self-identify for tracking usage and service information

Consumables Designed to Optimize Liquid Handling Performance

  • Single-, 8-, 12-channel pipetting tools utilize Thermo Scientific ClipTips* that securely seal to the pipetting head
  • These require low insertion and ejection force, extending the instrument components’ life
  • 96- and 384-channel pipetting heads utilize Thermo Scientific D.A.R.T.s* tips
  • D.A.R.T.s utilize a unique surface seal design that ensures accurate and precise pipetting by forming an even seal across all pipetting channels

Options for 2- or 6- Position Deck

  • Two stage capacity options, whether transitioning from handheld pipetting procedures or incorporating into an integrated system
  • Space Matters
    • Both can be swapped out with minimal effort and used in standalone or robotic-friendly format
    • Compact design allows it to fit on standard laboratory benches and into most biological hoods
    • 2- and 6- position units are equipped with a safety shield
    • The six position stage uses a unique dual-level design to further minimize space requirements

    User-Friendly Programming Options

    • Compatible with an onboard LCD interface or PC-based ControlMate* software
    • Options available for creating and editing simple or complex pipetting procedures
    • Ideal for procedures as diverse as automated serial dilution and cherry picking to 96/384 plate replications
  • Includes: Base Unit

    Compatible with: Versette Accessories

    Cat. No. Description

    • 650-05-96TW 96 Channel Tip Wash Station, Standard Height
    • 650-05-96TTW 96 Channel Tip Wash Station, Tall Height
    • 650-05-384STW 384 Channel Tip Wash Station, Standard Height
    • 650-05-384TTW 384 Channel Tip Wash Station, Tall Height
    • 650-08-VMNA Vacuum Manifold Kit, 100V, Includes plate risers, also compatible with Thermo Scientific PlateMate* 2×3
    • 650-08-VMEU Vacuum Manifold Kit, 220V, Includes plate risers, also compatible with Thermo Scientific PlateMate 2×3
    • 650-08-PRC Piercing Manifold Kit, for use with 96 format sample storage tubes,also compatible with PlateMate 2×3
    • 650-08-1.5ML-L 1.5ml Tube and Vial Adapter, accommodates lidded tubes and vials
    • 650-08-2ML 2ml Tube and Vial Adapter
    • 650-08-8ML 8ml Tube and Vial Adapter
    • 650-08-BCR Linear barcode reader
    • Thermo Scientific KingFisher*
    • Thermo Scientific Multidrop* Dispenser
    • Thermo Scientific Multiskan* FC and Multiskan GO Microplate Reader
    • Thermo Scientific Varioska*n microplate reader
    • Thermo Scientific RapidStak*, Orbitor, CataLyst Express

    Warranty and Service Offering: One Year Warranty

    Recommended for: Can be used in a number of applications in academia, pharma and biotech including drug discovery (including CROs), cell-based, genomics and proteomics.Ideal for life science researchers in low- to high-throughput laboratories currently performing hand-held pipetting tasks who want to move to automation or customers putting together integrated systems that require liquid handling.
